Digital Turbine Flowmeters [Compact]
| Name : |
Digital Turbine Flowmeters [Compact] |
| Code : |
KF510A |
| |
|
| |
Enquiry |
|
|
| |
Description : Specifications
| Diameter: | DN10mm-DN50mm (with PVDF triplet) |
| Accuracy: | ±1% - ±1.5% |
| Repeatability: | ±0.5% |
| Working temperature: | ≤80°C |
| Working pressure: | ≤0.8MPa |
| Installation method: | compact type |
| Power supply: | DC24V / battery power supply / AC220V |
| Output signal: | 4~20mA, passive pulse |
| Proctection class: | IP65 |
| Velocity range: | 0.3~6 m/s |
| Measure range: | 0.1~40 m3/h |
| Wetted material: | Sensor:PVDF Impeller:PVDF Shaft lever:ceramics |
| Seal ring: | Viton / EPDM |
| Alarm: | Upper limit, lower limit, totalizer |
![Digital Turbine Flowmeters [Compact]](/data/1048/prod/114316112157.png)
